VP-8x8 - Connecting the VP-8x8 8x8 VGA/UXGA Matrix Switcher
13
13
5.5.1
Setting the Delay
You can achieve clean-looking transitions when switching between non-genlocked
sources by setting the delay time
—ranging from 0sec to 3.5sec (in increments of
0.5sec)
—via the DELAY DIP-switches, as the next table defines. The VP-8x8 unit
is shipped (its factory default state) with no delay, that is, the DELAY DIP-switches are
set up for a 0sec delay.
SEC
DIP 1
DIP 2
DIP 3
0
OFF
OFF
OFF
0.5
OFF
OFF
ON
1.0
OFF
ON
OFF
1.5
OFF
ON
ON
2.0
ON
OFF
OFF
2.5
ON
OFF
ON
3.0
ON
ON
OFF
3.5
ON
ON
ON
5.5.2
Setting the Machine # DIP-Switches
The Machine # determines the position of a VP-8x8 unit, specifying which VP-8x8
unit is being controlled when several VP-8x8 units connect to a PC or serial
controller. Set the Machine # on a VP-8x8 unit via Setup DIPS 1, 2, 3 and 4,
according to the next table.
When using a standalone VP-8x8 unit, set the Machine # to 1. When connecting
more than one VP-8x8 unit, set the first machine (the Master) that is closest to the
PC, as Machine # 1 (DIP-switches are set to OFF).
Mach
#
DIP 1
DIP 2
DIP 3
DIP 4
Mach
#
DIP 1
DIP 2
DIP 3
DIP 4
1
OFF
OFF
OFF
OFF
9
ON
OFF
OFF
OFF
2
OFF
OFF
OFF
ON
10
ON
OFF
OFF
ON
3
OFF
OFF
ON
OFF
11
ON
OFF
ON
OFF
4
OFF
OFF
ON
ON
12
ON
OFF
ON
ON
5
OFF
ON
OFF
OFF
13
ON
ON
OFF
OFF
6
OFF
ON
OFF
ON
14
ON
ON
OFF
ON
7
OFF
ON
ON
OFF
15
ON
ON
ON
OFF
8
OFF
ON
ON
ON
16
ON
ON
ON
ON
