KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your RGBHV / Balanced Audio Matrix Switcher
4
To achieve the best performance:
Connect only good quality connection cables, thus avoiding interference,
deterioration in signal quality due to poor matching, and elevated noise-
levels (often associated with low quality cables)
Avoid interference from neighboring electrical appliances and position
your Kramer VP-88ETH / VP-84ETH / VP-82ETH / VP-66ETH /
VP-64ETH away from moisture, excessive sunlight and dust
4 Your RGBHV / Balanced Audio Matrix Switcher
This section describes each switcher as follows:
VP-88ETH (see Figure 1)
VP-84ETH (see Figure 2)
VP-82ETH (see Figure 3)
VP-66ETH (see Figure 4)
VP-64ETH (see Figure 5)
Table 1 and Table 2 define the front and rear panels of the machines.
