KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your RGBHV / Balanced Audio Matrix Switcher
12
4.1 Using the IR Transmitter
1
You can use the RC-IR2 IR transmitter to control the machine via the built-in
IR receiver on the front panel or, instead, via an external IR receiver 2 . The
external IR receiver can be located 15 meters away from the machine. This
distance can be extended to up to 60 meters when used with three extension
cables 3 .
Connect the external IR receiver to the REMOTE IR 3.5mm connector.
Control the RGBHV / balanced audio matrix switcher using the front panel
buttons, or remotely via the Kramer RC-IR2 Infra-Red Remote Control
Transmitter, via an external remote IR receiver (optional), or via RS-485 or
RS-232 serial commands transmitted by a touch screen system, PC, or other
serial controller.
1 From this section on, all the information is relevant to the VP-88ETH, VP-84ETH, VP-82ETH, VP-66ETH and VP-64ETH
machines, unless noted otherwise
2 P/N: C-A35M/IRR-50
3 P/N: C-A35M/A35F-50
