Kramer Electronics VP-84ETH User Manual
Page 3
KRAMER: SIMPLE CREATIVE TECHNOLOGY
Contents
ii
Figures
Figure 1: VP-88ETH 8x8 RGBHV / Balanced Audio Matrix Switcher
5
Figure 2: VP-84ETH 8x4 RGBHV / Balanced Audio Matrix Switcher
6
Figure 3: VP-82ETH 8x2 RGBHV / Balanced Audio Matrix Switcher
7
Figure 4: VP-66ETH 6x6 RGBHV / Balanced Audio Matrix Switcher
8
Figure 5: VP-64ETH 6x4 RGBHV / Balanced Audio Matrix Switcher
9
Figure 6: Connecting the VP-88ETH 8x8 RGBHV / Balanced Audio Matrix Switcher 15
Figure 7: Connecting the Balanced Stereo Audio Input/Output
16
Figure 8: Connecting the Unbalanced Stereo Audio Output
16
Figure 9: Connecting an Unbalanced Source to the Balanced Input
16
Figure 10: Connecting a PC without using a Null-modem Adapter
17
Figure 11: Controlling via RS-485 (for example, using an RC-3000)
18
Figure 12: Local Area Connection Properties Window
19
Figure 13: Internet Protocol (TCP/IP) Properties Window
20
Figure 14: VP-88ETH Dipswitches
21
Figure 15: Control Configuration via RS-232 and RS-485
28
Figure 16: Control Configuration via RS-485
30
Tables
Table 1: The RGBHV / Balanced Audio Matrix Switcher Front Panel
Features
10
Table 2: The RGBHV / Balanced Audio Matrix Switcher Rear Panel
Features
11
Table 3: Dipswitch Settings
21
Table 4: MACHINE # Dipswitch Settings
22
Table 5: Technical Specifications of the RGBHV / Balanced Audio Matrix Switchers 31
Table 6: Hex Codes for Switching the Master VP-88ETH
32
Table 7: Protocol Definitions
33
