KRAMER: SIMPLE CREATIVE TECHNOLOGY
Your RGBHV / Balanced Audio Matrix Switcher
10
Table 1: The RGBHV / Balanced Audio Matrix Switcher Front Panel Features
# Feature Function
1 IR Receiver The red LED is illuminated when receiving signals from the Kramer Infra-
Red remote control transmitter
2 POWER switch Illuminated switch for turning the unit ON or OFF
3 OUTPUT SELECTOR
Buttons 1
Select the output to which the input is switched
4 INPUT SELECTOR
Buttons 1
Select the input to switch to the output
5 TAKE Press to toggle between the Confirm mode 2 and the At Once mode (user
confirmation per action is unnecessary)
6 INPUT STATUS display Displays the selected input switched to the output (marked above each input)
7 RCL Button Press the RCL button followed by an INPUT button 3 to recall a setup from the
non-volatile memory
8 STO Button Press the STO button followed by an INPUT button 3 to store the current
settings
9 AFV Button When pressed 4 , actions relate to the video and audio channels. The audio
channels follow the video channels
10 AUDIO Button When pressed 4 , actions relate to audio
11 VIDEO Button When pressed 4 , actions relate to video
12 OFF Button An OFF-OUTPUT combination disconnects that output from the inputs; an
OFF-ALL combination disconnects all the outputs
13 ALL Button Press ALL followed by an INPUT button to connect that input to all the outputs
1 VP-88ETH has 8 inputs and 8 outputs; VP-84ETH has 8 inputs and 4 outputs; VP-82ETH has 8 inputs and 2 outputs;
VP-66ETH has 6 inputs and 6 outputs; VP-64ETH has 6 inputs and 4 outputs
2 When in the Confirm mode, the TAKE button blinks
3 In this case the INPUT button corresponds to the setup address number
4 The button illuminates
