VP-4x4K - Overview 3
3 Overview
The VP-4x4K is a true 4x4 matrix switcher for computer graphics (up to and exceeding
UXGA) signals and balanced stereo audio signals. The VP-4x4K lets you
simultaneously route any or all of the four inputs to any or all of the four outputs.
In addition, the VP-4x4K features:
• A video bandwidth of 400MHz that ensures transparent UXGA performance
• DC coupled inputs and outputs
• A selectable delayed switching mode (ranging from 0 to 3.5sec, in
increments of 0.5sec) for clean transitions (seamless switching) when
switching between non-genlocked sources
• Audio gain control for the inputs and the outputs
• Audio-follow-video and breakaway options
• Storing and recalling setup options
• A TAKE button for precise switch control that lets you execute multiple
switches all at once
• A LOCK button to prevent tampering with the front panel
• The ability to automatically detect connected input signals (the respective
button illuminates in green)
• Our innovative integrated sync processing; KRISP™ technology that lets you
achieve a sharp, stable image when the sync level is too low, by restoring
the sync signal waveform
Control the VP-4x4K using the front panel buttons, or remotely via:
• RS-485 or RS-232 serial commands transmitted by a touch screen system,
PC, or other serial controller
• The Kramer RC-IR3 infrared remote control transmitter
• The Ethernet
