8 VP-4x4K - Connecting the VP-4x4K
5 Connecting the VP-4x4K
Always switch off the power to each device before connecting it to your
VP-4x4K. After connecting your VP-4x4K, connect its power and then
switch on the power to each device.
This section describes how to:
• Connect the VP-4x4K rear panel (see Section 5.1 )
• Connect a balanced/unbalanced stereo audio output (see Section 5.2 )
• Connect the stereo audio output (see Section 5.3 )
• Connect several VP-4x4K machines (see Section 5.4 )
• Connect to the Ethernet (see Section 5.5 )
• Set the DIP-switches (see Section 5.6 )
5.1 Connecting the VP-4x4K Rear Panel
To connect the VP-4x4K, as illustrated in the example in Figure 2 , do the
following:
1. Connect up to four computer graphics video sources to the 15-pin HD INPUT
connectors (from INPUT 1 to INPUT 4).
2. Connect up to four unbalanced stereo audio sources (for example, the audio
source of the computer) to the AUDIO INPUT 3.5mm mini-plug connectors
(from 1 to 4).
Alternatively, you can connect a separate audio source (as shown for input 1 in
Figure 2 ), or no source at all.
3. Connect the four 15-pin HD OUTPUT connectors to up to four computer
graphics video acceptors (for example, displays).
4. Connect the four AUDIO OUTPUT terminal block connectors to up to four
balanced stereo audio acceptors (for example, balanced stereo audio
amplifiers with speakers).
See Section 5.2 .
5. Set the DIP-switches (see Section 5.6 ).
