50 VP-4x4K - Kramer Protocol
Identification Commands
Command Syntax Response
Set machine name
NAME MACHINE_NAME NAME MACHINE_NAME RESULT
Read machine name NAME? NAME MACHINE_NAME
Reset machine name
to factory default*
NAME-RST NAME-RST
MACHINE_FACTORY_NAME RESULT
*Note: machine name not equal to model name. This name relevance for site viewer identification of
specific machine or for network using (with DNS feature on).
MACHINE_NAME = Up to 14 Alfa-Numeric chars.
* Machine factory name = Model name + last 4 digits from serial number.
Set machine id
number
MACH-NUM MACHINE_NUMBER MACH-NUM OLD_MACHINE_NUMBER
,NEW_MACHINE_NUMBER RESULT
* Response will send after machine number has been changed. So the replay with header will be:
NEW_MACHINE_NUMBER @MACH-NUM OLD_MACHINE_NUMBER ,NEW_MACHINE_NUMBER
OK
Network Setting Commands
Set IP Address NET-IP IP_ADDRESS
NTIP NET-IP IP_ADDRESS RESULT
Read IP Address NET-IP?
NTIP?
NET-IP IP_ADDRESS
Read MAC Address
NET-MAC?
NTMC
NET-MAC MAC_ADDRESS
Set subnet mask
NET-MASK SUBNET_MASK
NTMSK NET-MASK SUBNET_MASK RESULT
Read subnet mask NET-MASK?
NTMSK?
NET-MASK SUBNET_MASK
Set gateway address
NET-GATE
GATEWAY_ADDRESS
NTGT
NET-GATE GATEWAY_ADDRESS
RESULT
Read subnet mask NET-GATE?
NTGT?
NET-GATE GATEWAY_ADDRESS
Set DHCP mode
NET-DHCP DHCP_MODE
NTDH NET-DHCP DHCP_MODE RESULT
Read subnet mask NET-DHCP?
NTDH?
NET-DHCP DHCP_MODE
DHCP_MODE =
0 – Don't use DHCP (Use IP set by factory or IP set command).
1 – Try to use DHCP, if unavailable use IP as above.
Change protocol
ethernet port
ETH-PORT PROTOCOL , PORT
ETHP ETH-PORT PROTOCOL ,PORT
RESULT
Read protocol ETH-PORT? PROTOCOL ETH-PORT PROTOCOL , PORT
