Technical Specifications

16

Table 9

lists the technical specifications of the VP-5THD.

Table 9: Technical Specifications of the VP-5THD (with 60m CAT 5 cable)

INPUT:

1 XGA on a 15-pin HD connector

OUTPUTS:

4 XGA on 15-pin HD connectors; 1 RJ-45 connector

MAX. OUTPUT LEVEL

1

:

1.7Vpp (XGA), 1.7Vpp (CAT 5)

BANDWIDTH (-3dB):

445MHz (XGA), 154MHz (CAT 5)

RESOLUTION:

Up to UXGA, up to 1080p

2

DIFF. GAIN

1

:

0.8% (XGA), 3.2% (CAT 5)

DIFF. PHASE

1

:

0.08Deg (XGA), 0.06Deg (CAT 5)

K-FACTOR

1

:

0.1% (XGA), <0.05% (CAT 5)

S/N RATIO

1

:

76dB (XGA), 73dB (CAT 5)

CONTROLS

1

:

LEVEL: –7.4dB to 3.5dB (CAT 5)
EQ.: 0 to 37.8dB @50MHz (CAT 5)

COUPLING

1

:

DC (XGA), AC (CAT 5)

POWER SOURCE:

230 VAC, 50/60 Hz. (115VAC, U.S.A.) 13VA

DIMENSIONS:

22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H (half 19”, 1U)

WEIGHT:

1.2kg (2.6 lbs) approx.

ACCESSORIES: Power

cord

Table 10

lists the technical specifications of the VP-5R.

Table 10: Technical Specifications of the VP-5R (with 30m CAT 5 cable)

INPUT: 1

RJ-45

connector

OUTPUTS:

5 XGA on 15-pin HD connectors

MAX. OUTPUT LEVEL

3

: 1.4Vpp

BANDWIDTH (-3dB):

150MHz

DIFF. GAIN

3

: 3.4%

DIFF. PHASE

3

: 0.05Deg

K-FACTOR

3

: <0.05%

S/N RATIO

3

: 74dB

CONTROLS

3

:

LEVEL: –8.2dB to 4.3dB
LINE EQ.: 0 to 30dB; OUT EQ.: 0 to 8.6dB

COUPLING

3

: AC

POWER SOURCE:

230V AC, 50/60 Hz. (115V AC, U.S.A.) 9.2VA

DIMENSIONS:

22cm x 18cm x 4.5cm (8.7” x 7” x 1.7”) W, D, H (half 19”, 1U)

WEIGHT:

1.2kg (2.6 lbs) approx.

ACCESSORIES: Power

cord

1 For the VP-5THD to TP-120 SETUP

2 The HD resolutions apply to the HD version of the unit

3 For the VP-5R to WP-110 SETUP
