© MuxLab Inc. Passive CCTV Hub Installation Guide
Page 20
Power-Thru Mode (500024/500029)
Voltage Pcam (W) Vcam 1 min (V) Dist Spec 2 max (Feet) Dist Spec 2 max (m)
12 VDC/AC 5 10.80 130 43
12VDC
AC camera
10 10.80 65 21
20 10.80 32 11
30 10.80 22 7
40 10.80 16 5
50 10.80 13 4
24 VAC 5 21.60 518 170
24VAC camera 10 21.60 259 85
20 21.60 130 43
30 21.60 86 28
40 21.60 65 21
50 21.60 52 17
28 VAC 5 21.60 1382 454
24VAC camera 10 21.60 691 227
20 21.60 346 113
30 21.60 230 76
40 21.60 173 57
50 21.60 138 45
Notes:
1. Distances are specified for temperatures of 20 o C to 30 o C
2. Maximum distances based on 10% loss of voltage. For 28VAC, a 24VAC camera was used.
3. Distances specified are 90% of distances calculated.
4. If 22AWG gage wire is used, there would be an increase in distance of approximately 56%.
