© MuxLab Inc. Passive CCTV Hub Installation Guide
Page 19
5.
Distance Tables
The following tables provide the maximum distances for remote power via Cat5 twisted
pair when a port on the Passive CCTV Hub is set to Pass-Thru Mode (500022) or Power-
Thru Mode (500024/500029).
Pass-Thru Mode (500022) – Two (2) Twisted Pairs
Voltage Pcam (W) Vcam 1 min (V) Dist Spec 2 max (Feet) Dist Spec 2 max (m)
12 VDC/AC 5 10.80 86 28
12VDC/AC camera 10 10.80 43 14
20 10.80 22 7
30 10.80 14 5
40 10.80 11 4
50 10.80 9 3
24 VAC 5 21.60 346 113
24VAC camera 10 21.60 173 57
20 21.60 86 28
30 21.60 58 19
40 21.60 43 14
50 21.60 35 11
28 VAC 5 21.60 922 302
24VAC camera 10 21.60 461 151
20 21.60 230 76
30 21.60 154 50
40 21.60 115 38
50 21.60 92 30
