Unit Physical Data
HBH/V Series
HB Series 006 009 012 015 018 024 030 036 042 048 060
Compressor (1 Each) Rotary Scroll
Factory Charge R410A (oz) 17 18.5 23 32 43 43 47 50 70 74 82
PSC Fan Motor & Blower
Fan Motor Type/Speeds PSC/3 PSC/3 PSC-3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3 PSC/3
Fan Motor (hp) 1/25 1/10 1/10 1/6 1/6 1/4 3/4 1/2 3/4 3/4 1
Blower Wheel Size (Dia x w) 5x5 5x5 6x5 8x7 8x7 9x7 9x7 9x8 9x8 10x10 11x10
Water Connection Size
IPT 1/2” 1/2” 1/2” 1/2" 1/2" 3/4" 3/4" 3/4" 3/4" 1" 1"
Vertical
Air Coil Dimensions (H x W) 10x15 10x15 10x15 20x17.25 20x17.25 20x17.25 20x17.25 24x21.75 24x21.76 24x28.25 24x28.25
Filter Standard - 1" Throwaway 10x18 10x18 10x18 20x20 20x20 20x20 20x20 24x24 24x24 1-14x24, 1-18x24 1-14x24, 1-18x24
Weight - Operating (lbs.) 103 105 114 153 158 189 197 203 218 263 278
Weight - Packaged (lbs.) 113 115 124 158 163 194 202 209 224 270 285
Horizontal
Air Coil Dimensions (H x W) 10x15 10x15 10x15 16x22 16x22 16x22 16x22 20x25 20x25 20x35 20x35
Filter Standard - 1" Throwaway 10x18 10x18 10x18 16x25 16x25 18x25 18x25 20x28 or 2-20x14 20x28 or 2-20x14 1-20x24, 1-20x14 1-20x24, 1-20x14
Weight - Operating (lbs.) 103 105 114 153 158 174 182 203 218 263 278
Weight - Packaged (lbs.) 113 115 124 158 163 179 187 209 224 270 285
Notes:
Models 006-012 have spring compressor mounts, all others have grommets,TXV expansion device, and 1/2” & 3/4” electrical knockouts.
Unit Maximum Water Working Pressure
Options Max Pressure PSIG [kPa]
Base Unit 500 [3,445]
Discharge Pressure
Water Regulating Valve
140 [965]
Use the lowest maximum pressure rating when multiple options are combined.
