Weather hood size 36 to 60, Weather hood size 8 to 30 – COOK Propeller Wall Fans User Manual
Page 13
13
Weather Hood Size 36 to 60
1
3
5
6
4
8
2
7
8
8
8
9
Part
Description
Description
1
Top Panel, Piece 1
6
Bird Screen Support
2
Top Panel, Piece 2
7
1/2” Mesh Galvanized Bird Screen
3
Right Side Panel
8
1/4” X 1/2” Speed Screw
4
Left Side Panel
9
5/16 SAE Steel Washer
5
Bottom Panel
Weather Hood Size 8 to 30
5
7
6
6
1
3
4
2
6
Part
Description
Description
1
Top Panel
5
1/2” Mesh Galvanized Bird Screen
2
Right Side Panel
6
1/4” X 1/2” Speed Screw
3
Left Side Panel
7
5/16 SAE Steel Washer
4
Bottom Panel
