COOK Duct Blower - Manual (Page 8)

8
Corporate Offices: 2015 E. Dale Street Springfield, MO 65803 417.869.6474
lorencook.com
DB IOM - March 2011
Limited Warranty
Loren Cook Company warrants that your Loren Cook fan was manufactured free of defects in materials and workmanship, to the extent stated herein. For a period of one (1)
year after date of shipment, we will replace any parts found to be defective without charge, except for shipping costs which will be paid by you. This warranty is granted only to
the original purchaser placing the fan in service. This warranty is void if the fan or any part thereof has been altered or modified from its original design or has been abused, mis-
used, damaged or is in worn condition or if the fan has been used other than for the uses described in the company manual. This warranty does not cover defects resulting from
normal wear and tear. To make a warranty claim, notify Loren Cook Company, General Offices, 2015 East Dale Street, Springfield, Missouri 65803-4637, explaining in writing,
in detail, your complaint and referring to the specific model and serial numbers of your fan. Upon receipt by Loren Cook Company of your written complaint, you will be notified,
within thirty (30) days of our receipt of your complaint, in writing, as to the manner in which your claim will be handled. If you are entitled to warranty relief, a warranty adjustment
will be completed within sixty (60) business days of the receipt of your written complaint by Loren Cook Company. This warranty gives only the original purchaser placing the fan
in service specifically the right. You may have other legal rights which vary from state to state.
SDB and DBX Parts List
2
1
3
4
5
6
7
8
9
10
AIRFLOW
11
12
13
Part No.
Description
SDB Sizes 100 - 180 SDB Sizes 210 - 245 DBX Sizes 10 -18
1 Rubber Isolators (4) Rubber Isolators (4) Rubber Isolators (4)
2 Hanger Channel (2) Hanger Channel (2) Hanger Channel (2)
3 Driver Sheave Driver Sheave Driver Sheave
4 Motor Motor Motor
5
Pivoting Motor Base (shown) — Pivoting Motor Base (shown)
— Slide Motor Base (not shown) —
6 Belt Set Belt Set Belt Set
7 Driven Sheave Driven Sheave Driven Sheave
8 Blower Blower Blower
9 Blower Brackets (2) Blower Brackets (2) Blower Brackets (2)
10 Outlet Flange Outlet Flange Outlet Flange
11 Wheel Wheel Wheel
12 Shaft Shaft Shaft
13 Bearings (3) Bearings (3) Bearings (3)
