Apollo 150 User Manual
Page 97
User Manual version 2007
APOLLO 120/150 III
6-87
6.1.5.9. INV1: LCD Inverter Connector
6.1.5.10. FDD1: FDD connector
Pin # Signal
Pin # Signal
1
VCC
2
INDEX#
3
VCC
4
DSA#
5
VCC
6
DSKCHG#
7
NC
8
NC
9
NC
10
MOA#
11
NC
12
DIR#
13 RWC#
14
STEP#
15
GND
16
WD#
17
GND
18
WE#
19
GND
20
TRAK0#
21
GND
22
WP#
23
GND
24
RDATA#
25
GND
26
HEAD#
Pin # Signal
1 Backlight ADJ
2 GND
3 Backlight Enable
4 12V
1
4
