APOLLO 120/150 III 4-38
4.5.2. When System Memory Clock = 100MHz
The following tables contain all graphic support modes under
the following condition and are classified under three output
modes (single mode, mirror mode and multiple-monitor
mode).
System memory clock = 100MHz
Memory bus width = 64 bit
Video memory size = 8MB or above
4.5.2.1. Single Display Mode
Resolution Bpp CRT1 LCD
640*480 8 60, 72, 75, 85, 100, 120, 160, 200 60, 70, 75
16 60, 72, 75, 85, 100, 120, 160, 200 60, 70, 75
32 60, 72, 75, 85, 100, 120, 160, 200 60, 70, 75
800*600 8 56, 60, 72, 75, 85, 100, 120, 160 60, 70, 75
16 56, 60, 72, 75, 85, 100, 120, 160 60, 70, 75
32 56, 60, 72, 75, 85, 100, 120, 160 60, 70, 75
1024*768 8 43, 60, 70, 75, 85, 100, 120 60, 70, 75
16 43, 60, 70, 75, 85, 100, 120 60, 70, 75
32 43, 60, 70, 75, 85, 100 60, 70, 75
1280*1024 8 43, 60, 75, 85 60
16 43, 60, 75, 85 60
32 43, 60
1600*1200 8 60, 65, 70, 75, 85
16 60, 65, 70, 75, 85
32
1920*1440 8 60
16 60
32
