APOLLO 120/150 III
6-99
6.2.3.7. FDD1: External FDD Connector
Pin # Signal Pin # Signal Pin # Signal
1 RWC#
6 WP#
11 RDATA#
2 INDEX# 7 TRAK0# 12 HEAD#
3 MOA#
8 WE#
13 DSKCHG#
4 DSA#
9 WD#
14 GND
5 DIR#
10 STEP#
15 GND
6.2.3.8. J11: USB 1 , USB2 Connector
USB1
USB2
Pin # Signal
Pin # Signal
1
USBVCC
1 USBVCC
2
Data-
2 Data-
3
Data+
3 Data+
4
Gnd
4 Gnd
6.2.3.9. DIO1: RJ-11 Connector
Pin # Signal
Pin # Signal
1 +12V
2
IN_0
3 IN_1
4
GND
5 OUT_0
6
OUT_1
6.2.3.10. LAN1: RJ-45 Ethernet Connector
Pin # Signal
Pin # Signal
1 TD+
2
TD-
3 RO+
4
NC
5 NC
6
RO-
7 NC
8
NC
