6.1.5. Connectors & Pin Assignment
The table below lists the function of each connector on the PC
610. Their corresponding pin assignments will be shown in
the following sections.
Connector Description
PWR1
Power Connector For Touch Screen
PWR2 Power Connector For CD-ROM
PWR3 ATX Power Connector
J2 CD Audio In
J7 HDD LED & ACPI LED & SMI
J8 IR/CIR connector
J9 KB/Mouse/Speaker/LED Connector
SCSI 1 I/O Connector
SCSI 2 I/O Connector
FAN1 CPU FAN Connector
FAN2 System FAN Connector
SW1 ATX Power ON/OFF
LCD LCD Connector
INV1 LCD Inverter connector
FDD1 FDD connector
IDE1 Primary IDE connector
IDE2 Primary IDE connector
COM3 Serial Port 3 (For Touch Screen)
