User Manual version 2207
APOLLO 120/150 III 4-34
4.5. 2 nd Display Graphic Support Mode
The APOLLO can support
SINGLE DISPLAY MODE
and
DUAL DISPLAY
MODE
. For dual display mode, it can support MIRROR
MODE
(same screen) or
MULTIPLE
-
MONITOR MODE
(different screens).
P
LEASE NOTE
THAT THE
MULTIPLE
-
MONITOR MODE ONLY WORKS WHEN
THE OPERATING SYSTEM IS
W
INDOWS
98
OR
W
INDOWS
ME
OR
W
INDOWS
XP.
The APOLLO itself is onboard with an AGP LCD/VGA
controller. When dual display mode is activated, it can
support a LCD panel (digital TTL) and a CRT or an analog
monitor at either mirror mode or multiple-monitor mode.
The following sections describe all the graphic support modes
based on system memory clock frequency (66MHz, 100MHx
and 133MHz). All these tables apply only to video memory
size is equal or larger than 8MB.
4.5.1. When System Memory Clock = 66MHz
The following tables contain all graphic support modes under
the following condition and are classified under three output
modes (single mode, mirror mode and multiple-monitor
mode).
System memory clock = 66MHz
Memory bus width = 64 bit
Video memory size = 8MB or above
