Apollo 150 User Manual
Page 108
User Manual version 2207
APOLLO 120/150 III
6-98
6.2.3.4. CN1: DC Power Output
Pin # Signal
Pin # Signal
1
GND
5
+5V
2
GND
6
+12V
3
+5V
7
GND
4
+12V
8
GND
6.2.3.5. LPT1: D-SUB-25 Parallel Port
Pin # Signal
Pin # Signal
1
STRB#
14 AFD#
2
DATA 0
15 ERROR#
3
DATA 1
16 INIT#
4
DATA 2
17 SLINT#
5
DATA 3
18 GND
6
DATA 4
19 GND
7
DATA 5
20 GND
8
DATA 6
21 GND
9
DATA 7
22 GND
10 ACK#
23 GND
11 BUSY
24 GND
12 PE
25 GND
13 SLCT
6.2.3.6. CRT1: VGA (D-SUB 15 Pin)
Pin # Signal
Pin # Signal
Pin # Signal
1 Red
6 GND
11 NC
2 Green 7 GND
12 DDCDATA
3 Blue
8 GND
13 Hsync
4 NC
9 NC
14 Vsync
5 GND
10 GND
15 DDCCLK
