APOLLO 120/150 III
6-97
6.2.3.1. KB1: PS/2 Keyboard Connector
Pin # Signal
1
KBDATA
2
NC
3
GND
4
SB5V
5
KBCLK
6
NC
6.2.3.2. KBMS: PS/2 Mouse
Pin # Signal
1
MSDATA
2
NC
3
GND
4
5V
5
MSCLK
6
NC
6.2.3.3. COM1, COM2, COM4: DB-9
Pin # Signal
Pin # Signal
1
DCD
6
DSR
2
RXD
7
RTS
3
TXD
8
CTS
4
DTR
9
RI (+5V/12V)
5
GND
