APOLLO 120/150 III
6-102
6.2.3.15. SCSI 2: KB/MS/VGA/LAN USB/EXT. FDD
Pin # Signal
Pin # Signal
1 GND
35 GND
2 GND
36 GND
3 HSYNC
37 UV0+
4 VSYNC
38 UV0-
5 RED
39 UV1+
6 GREEN
40 UV1-
7 BLUE
41 GND
8 DDCCLK
42 GND
9 DDCDATA
43 GND
10 GND
44 RX+
11 GND
45 RX-
12 GND
46 TX+
13 RWC#
47 TX-
14 INDEX#
48 GND
15 MOA#
49 GND
16 DSA#
50 GND
17 DIR#
51 LINE IN _R
18 STEP#
52 LINE IN_L
19 WD#
53 MIC
20 WE#
54 HP_R
21 TRAK0#
55 HP_L
22 WP#
56 NC
23 RDATA#
57 GND
24 HEAD#
58 GND
25 DSKCHG#
59 GND
26 GND
60 KBDATA
27 GND
61 KBCLK
28 BACK LIGHT
62 MSDATA
29 NC
63 MSCLK
30 VCC3
64 SB5V
31 VCC3
65 SB5V
32 VCC3
66 SB5V
33 VCC3
67 SB5V
34 VCC
68 SB5V
