Others
Using the stereo shotgun microphone (DMW-MS2:optional), you can switch between the
gun (ultra-directional) recording and the wide range stereo recording.
Preparations:
•
Close the built-in flash, and then turn this unit off.
•
Remove the hot shoe cover that is attached to the camera.
1
Attach the dedicated stereo shotgun microphone to this unit, and then turn this
unit on.
2
Select [Special Mic.] on the [Motion Picture] menu.
•
The menu items are displayed only when the stereo shotgun microphone is connected.
3
Press 3/4 to select the
Item
and then press [MENU/SET].
•
While the external microphone is connected, [
] is displayed on the screen.
•
When the external microphone is connected, [Mic Level Disp.]
is automatically set to
[ON], and the mic level is displayed on the screen.
•
When attaching the stereo shotgun microphone, do not hold only the stereo shotgun
microphone because it may detach from the camera.
•
[Wind Cut] in the [Motion Picture] can reduce the wind noise effectively.
•
Do not open the built-in flash when the stereo shotgun microphone is attached.
•
If the noises are recorded when you use an AC adaptor (optional), use a battery.
•
Read the operating instructions of the stereo shotgun microphone for details.
External Microphone (optional)
[STEREO]:
Allows stereo recording of sound over a wide area.
[SHOTGUN]: Allows recording from one direction by shutting out background and
surrounding noise.
