44 Asanté FriendlyNET Cable/DSL Router
server can handle multiple network services, only one server can be assigned to
each network service.
For each Service Port, select one computer to handle all requests to this port.
For the Server IP, enter the computer’s last octet of its IP address. For example,
if you have four computers, you may want to configure FTP or other servers,
then you need to specify virtual server mapping as shown in the example below:
Tip: To quickly enable popular services, use the “Common Ports” at the bottom
of the screen or press the Help button to see a list of service ports. You should
have a static IP address to use this feature.
Always remember to restart the router to complete the changes after entering or
changing the values.
Port
Service
Server IP
Enable
21
FTP Server
192.168.123.100
√
25
Email Server
192.168.123.101
√
80
Web Server
192.168.123.102
√
110
Post Office Server
192.168.123.103
√
