4 Asanté FriendlyNET Cable/DSL Router
4. Once the information has been recorded, choose Using DHCP Server from
the Configure: pull-down menu. Close the dialog box and save your
changes.
Repeat steps 1, 2, and 4 to configure additional Macs you wish to add to the
router.
W INDOWS 95/98/M E
1. From the Windows Start button, choose Run. In
the dialog box, type winipcfg and click OK.
2. Choose your computer’s Ethernet adapter from
the first drop-down list.
Tip: The PPP setting is usually for your dial-up
analog modem. Don’t choose this selection.
3. Expand this dialog box by clicking on the More
Info >> button.
4. Complete the information in this table:
Tip: Next to the DNS Servers
field, click the button to show the Secon-
dary DNS (if available).
5. From the Windows Start button, choose
Settings and select Control Panel. Double-
click the Network icon.
6. In the Configuration tab, highlight the TCP/IP
protocol line associated with your network
card adapter.
Item No. IP Configuration Description Your Setting
1 Host Name Host Name
2 DNS Servers Primary DNS
3 Secondary
4 Adapter Address MAC Address
5 IP Address WAN IP Address
6 Subnet Mask WAN Subnet Mask
7 Default Gateway WAN Gateway
Windows Configuration Table
