Connecting an External Display
77
4 Verify that the power cord is plugged into the multimedia computer display
and an AC outlet.
To connect a projector to the notebook
You can also connect a projector, such as the Sony LCD Projector, to the
notebook or port replicator.
1 Shut down the computer before you connect the projector.
2 Locate the VGA (Monitor) port on the rear panel of the notebook and the
Headphone jack on the right panel of the notebook.
✍
Connect the cable before you turn on the notebook, otherwise Fn + F8 will not work.
You cannot use the Fn + F8 function to switch between LCD and TV once a DVD is
inserted into the optical drive.
Connecting a Multimedia Computer Display to the Notebook
✍
See the manual that came with your multimedia computer display for more
information on its installation and use.
R
Audio In
L
Video In
Multimedia display
Power cord
Display cable (not supplied)
To AV Out jack
