To remove the notebook from the port replicator – Sony PCG-GRX500K User Manual
Page 63
Connecting a Port Replicator
63
4
Align the connector on the bottom of the notebook with the port replicator
connector and push the notebook down until it clicks into place.
5
Turn on the notebook.
To remove the notebook from the port replicator
1
Double-click
in the task tray. The “Unplug or Eject Hardware” dialog
box opens.
2
Select all active peripheral devices, and click Stop. Then click OK to remove
the device safely from the system.
3
Once all active peripheral devices are disengaged, disconnect the device
connectors from the port replicator.
Attaching Notebook to Port Replicator
✍
When attaching your notebook to the port replicator, do not attempt to insert or
remove the battery pack. Lifting and turning the notebook with an attached port
replicator could cause a temporary loss of power.
Notebook
Port replicator
