APPENDIX A. CONNECTOR PIN DEFINITIONS
The following tables provide the pin assignments for the NetVanta 300 Series units.
Table A-1. ADSL Connector Pinouts
Pin
Name
Description
1, 2
—
Unused
3
T
ADSL Tip
4
RT
ADSL Ring
5, 6
—
Unused
Table A-2. 10/100BaseT Ethernet Port Pinouts
Pin
Name
Description
1
TX1
Transmit Positive
2
TX2
Transmit Negative
3
RX1
Receive Positive
4, 5
—
Unused
6
RX2
Receive Negative
7, 8
—
Unused
