NetVanta 300 Series Hardware Installation Guide

Introduction to the NetVanta Solution

61200422L1-34D

This hardware installation guide describes the NetVanta 300 Series, details basic functionality, gives
installation instructions, and lists unit specifications. For more information on router configuration for a
specific application, refer to the quick configuration documents provided on the ADTRAN website at
www.adtran.com. For details on the command line interface, refer to the AOS Command Reference Guide,
also on the website.

Routing Protocol

OSPF, RIP, BGP, and static

Routed Protocol

Bridging (other protocols)

PPP

LCP, IPCP, BCP

Disaster recovery

WAN Protocol

ATM

Quality of Service

(QoS)

Priority and Weighted Fair Queuing (WFQ)

DiffServ packet marking and recognition

Optional Virtual

Private Network

(VPN)

IPSec Mode: Tunnel

Encryption: DES, 3DES, and AES

Diffie Hellman Group Support: Group 1 - MODP 768; Group 2 - MODP 1024

HAS Algorithms: MD5-HMAC, SHA1-HMAC

Authentication Mechanisms: XAUTH, digital certificates,preshared keys

Key Management: IKE (ISAKMP/Oakley)

IKE Modes: Main, Aggressive

Environmental

Operating Temperature: 0°C to 50°C; humidity 8 to 100 percent, noncondensing

Storage/Transport Temperature: -20°C to 70°C; humidity 5 to 100 percent

Physical

Dimensions: 7.5-inch W x 1.75-inch H x 5.375-inch D

Weight: 0.8 lb

Power:

NetVanta 340/NetVanta 347:120 VAC, 60 Hz, double insulated
NetVanta 344: 12 VDC

Compliance

NetVanta 340/347:

NetVanta 344 Annex A:

NetVanta 344 Annex B:

FCC Part 15, Class B

ACTA/FCC Part 68

AS/ACIF S043

IC CS-03

EN 60950

UL/CUL 60950

AS/ACIF S043

IEC 60950

AS/ACIF S002

AS/NZS 60950

EN 60950

RoHS compliant

IEC 60950

(Telecommunications

UL/CUL 60950

exemption)

AS/NZS 60950
RoHS compliant
(Telecommunications exemption)

Table 1. Features and Specifications (Continued)
