ENGLISH 19
Contents Page
1 Safety information 22
1.1 Correct use 22
1.2 General safety instructions 22
1.3 Safety information 24
2 Technical data 25
3 Functions of the thread-tapping machine 25
3.1 Overview A 25
3.2 Functional description 26
3.3 Accessories 26
4 Preparations for operation 26
4.1 Transporting the thread-tapping machine 26
4.2 Setting up the machine 26
4.3 Electrical connection 27
4.4 The thread-tapping oil 27
4.5 Checking the thread-tapping oil 28
4.6 Setting the supplied thread-tapping oil quantity 28
4.7 Draining off the oil 28
5 Operation of the thread-tapping machine 28
5.1 Clamping the workpieces B 28
5.2 Cutting the workpiece with the pipe cutter C 29
5.3 Reaming the workpieces D 29
5.4 Removing and installing the thread jaws from and in the thread-
Tappinghead E 30
5.4.1 Automatic thread-tapping head 30
5.4.2 Standard thread-tapping head 30
5.5 Installing and removing the thread-tapping head into
and out of the bed carriage 31
5.6 Changing the thread size F 31
5.7 Tapping threads G 31
5.8 Setting the thread length (only Automatic thread-tapping head) 32
5.9 Setting the thread depth (only automatic thread-tapping head) 32
5.10 Thread-tapping in 2 work steps
(only automatic thread-tapping head 2 ½” … 3” / 4”) 33
5.11 Removing the workpiece 33
