【6】 Angle mode
Operation/Results Work Button Display
Display examples
meter yards feet
Elevation (˚) Depression (˚)
6 Measurement with Angle mode
6-1
Seeking your target
(Align the reticle with target)
Angle (from horizontal)
6-2
Measurement
(Laser irradiate symbol is
displayed.)
With the POWER button depressed,
continuous measurement is possible for
up to 20 seconds.
(When done, 6-3 display appears.)
POWER
6-3 Failure to measure Repeat step 6-1.
6-4 Measurement OK
Angle (from horizontal)
Follow by or 6-1.
13
9 Power off
Regardless of process, after 30 seconds
since your last operation, power turns off.
30 seconds
without
operation
【7】 Vertical separation (height between two points) mode
Operation/Results Work Button Display
Display examples
meter yards feet
Elevation (˚) Depression (˚)
7 Measurement with Vertical separation (height between two points) mode
7-1
Seeking your target
(Align the reticle with target)
Vertical separation
(height between two points) (1st target)
blinks
7-2
Measurement
(Laser irradiate symbol is
displayed.)
POWER
7-3 Failure to measure
Follow by 7-1
Repeat 7-1, 7-2, 7-3 until measurement is
complete.
blinks
7-4 Measurement OK Height of 1st target (from Horizontal)
blinks 15.2 16.6 50.0
7-5
Aiming (2nd target)
(Align the reticle with
target)
Vertical separation (height between two
points) (2nd target)
(Result shown is the height of the 1st target)
blinks
15.2 16.6 50.0
7-6
Measurement
(Laser irradiate symbol is
displayed)
POWER
7-7 Failure to measure
Follow by 7-5
Repeat 7-5,7-6 and 7-7 until measurement
is complete
blinks
7-8 Measurement OK
Vertical separation
(height between two points)
After 2 seconds, move to7-1
21.4 23.4
9 Power off
Regardless of process, after 30 seconds
since your last operation, power turns off.
30 seconds
without
operation
Operation and internal display
