29
The brake endpoint adjustment, located at Grip Lever A, allows the maximum servo travel
on the braking side of the throttle trigger to be increased or decreased from 100% to 0%
(off). This function is very useful in race conditions as it allows the racer to custom tailor
the “panic” brake value to maximize the car’s braking power for the current track conditions.
Please note that since the brake endpoint value shown in the BRG screen is a percentage of
the total braking value established in the Travel Adjust function (page 20), the value will not
always increase or decrease, or beep once for each time the Grip Lever A is moved.
To adjust the brake endpoint value, move the electronic Grip Lever A either left (–) or right
(+). As soon as the grip lever is moved, the BRG Travel Adjust screen will appear and will
continue to be displayed unless the Grip Lever A is untouched for a period of five seconds.
To reset the brake endpoint value to the factory preset setting of 50%, press the INCREASE
and DECREASE keys at the same time while the BRG screen is displayed.
Press the INCREASE or DECREASE keys at the
same time to reset brake endpoint trim value to
the factory preset (50%)
INCREASE DECREASE
CLEAR
DIRECT
+ –
Grip Lever A:
Brake Endpoint
Adjustment BRG
Brake Endpoint
Adjustment
Move Grip Lever A to the left or right to decrease or increase values
Decrease
Grip Lever A
Increase
brg
50
Indicates current
value
TRV ADJ
–
