20
The Travel Adjust feature of the DX2 allows the maximum travel of both the steering or
throttle. The adjustment range is from 0 % to 125%. The travel adjustment is factory set to
100% for both channels. The travel adjustment value displayed on the screen depends on
the current position of the steering wheel, trigger, or trim lever to be adjusted. This feature
is very useful either to maximize servo travel or to reduce servo over-travel to eliminate
servo binding (servo moves further than control mechanism allows), without the need for
mechanical linkage adjustment.
The screens below are accessed by turning the wheel to the desired direction to be adjusted
(left or right), by moving the trigger to the forward or backward (brake) position, or by
moving the Grip Lever A to the forward or back positions.
Travel Adjust
(Function Mode)
stl
100
TRV ADJ.
str
100
TRV ADJ.
fwd
100
TRV ADJ.
Indicates Steering Left travel adjustment
Indicates current
value
Indicates Steering Right travel adjustment
Indicates current
value
Indicates Forward Throttle travel adjustment
Indicates current
value
–
–
–
