Packing List
Check-marked for applicable model and content
Intel  Pentium 3 Socket 370, AMD Duron, Athlon, MP,
XP socket 462
Intel  Xeon  Processor, socket
603/604
Intel  Pentium 4 socket 478 Bare kit without water-block
AMD  Athlon 64 & Opteron Deluxe Kit
Qty Item Incl
.
Qty Item Incl.
1 MCW6000-A  CPU water-block for
AMD  K7 processors (Duron  ,
Athlon  MP and XP)
1 40” length Coolsleeves  clear coils D
1 MCW6000-P  CPU water-block for
Intel  Pentium  4 processors
1 FBK525  assy. incl. (1) ½” fill & bleed kit, (2)
7/32-5/8” worm drive hose clamps
D
1 MCW-6000PX  CPU water-block
for Intel  Xeon  processors
2 2 ½ ft long ½” OD vinyl tubes for fill and bleed
operations D
1 MCW6000-64  CPU water-block
for AMD  K8 processors (Athlon 
64 and Opteron)
1 MCP600  12 Volts DC industrial pump with
retention screws
D
1 MCR80-F2  radiator assy. incl. (1)
Radiator, (1) 80x80x25mm fan, (1)
fan guard, (4) #6 x 1 ¼” screws, (4)
#6 x 3/8” screws, (2) 7/32-5/8”
quick-connect fittings
D 7 Feet ½” OD high quality vinyl tubing D
1 1ft of ½” tube ID thick wall Clearflex
tubing, (2) ½” to 3/8” barb nylon
adapters D 1 2 oz bottle HydrX  specially formulated coolant D
1 Additional MCR80-F2  radiator
assy. incl. (1) Radiator, (1)
80x80x25mm fan, (1) fan guard, (4)
#6 x 1 ¼” screws, (4) #6 x 3/8”
screws, (2) 7/32-5/8” quick-connect
fittings
1 Set of 2 of quick-connect 3/8” tube to ½” tube
union blue and red collets for MCW6000 water-
block D
1 MCW50 VGA cooler 1 MCW20-R chipset cooler
