Intel® pentium® 4 and pentium® d socket lga 775 – Swiftech H20 220 APEX ULTRA PLUS REV2 User Manual
Page 11
Copyright Swiftech 2007 – All rights reserved – Last revision date: 10-08-07 - Information subject to change without notice – URL:
http://www.swiftech.com
Rouchon Industries, Inc., dba Swiftech – 3700 Industry Avenue, Suite 104, Lakewood, CA 90712 – Toll free (US): 888-857-9438 – Fax 562-595-8769 - E Mail: help@
Swiftech.com
PAGE 11 of 32
Intel® Pentium® 4 and Pentium® D
Socket LGA 775
Intel® Pentium® 4 and Pentium® D Socket LGA 775
First, install the 775 backplate
Peel of the protective paper and position the backplate at the back
of the motherboard. Firmly press it into the motherboard.
