Swiftech H20 220 APEX ULTRA User Manual
Page 20
Copyright Swiftech 2007 – All rights reserved – Last revision date: 06-19-07 - Information subject to change without notice – URL:
http://www.swiftech.com
Rouchon Industries, Inc., dba Swiftech – 3700 Industry Avenue, Suite 104, Lakewood, CA 90712 – Toll free (US) 888-857-9438 – Fax 562-595-8769 - E Mail:
PAGE 20 of 27
Permanent installation to the chassis, and exploded
view
Specifications:
Nominal voltage / Connector
12 V DC / Molex 4 pin
Maximum pressure
50 PSI (3.5 BAR)
Operating voltage range
8 to 24 VDC
Maximum head
10 ft (3.1 m)
Nominal current (@ 12 V)
2 amps
Maximum discharge
~ 317 GPH (1200 LPH)
Nominal power (@ 12 V)
24 W
Temperature range
32 °F to 140°F (0 °C to 60 °C)
Motor type
Brushless, microprocessor controlled
Weight
1.4 LB (650 gr.)
Impeller Housing material
Noryl®
Connection size
½" barbs
