Swiftech MCW5000 64RH User Manual
Page 2
6-32 Philips screw
Nylon shoulder
washer
Spring
Aluminum
tension limiter
Nylon spacer
CPU
Motherboard
Method 2:
It is also possible to install the MCW5000-64
without the stock plastic retention frame.
However, you MUST then use the nylon
spacers provided with your accessories
package as shown in figure 7, page 2. These
are necessary to replace the stock plastic
retention frame and to provide support to the
entire assembly
Page 2 of 2
