8
Installation
Electrical connection
The service line will enter trough the rear of the oven and
connected to the terminal block (see diagram).
1. Remove the bottom trim and control panel. Removal
of the body side is not necessary.
2. Remove knock-out in the rear of the unit and run the
supply power line to terminal block and connect the
wires.
3. Reinstall the control panel and the bottom trim.
The Blodgett Oven Company cannot assume responsi-
bility for loss or damage suffered as a result of improper
installation.
Connect wires to
terminal block
Run supply line
through the knock-out
Figure 7
