Chapter 12: Rapid Spanning Tree Protocol Commands

110

bridges connected to the port. If the port receives
STP BPDU packets in response, the port changes to
STP compatible mode. If the port receives RSTP
BPDU packets, it operates in RSTP.

Note
All changes to a port’s RSTP settings, with the exception of port cost,
are activated immediately. A change to the port cost value requires
you to reset the switch. A new port cost value is not implemented
until the unit is reset.

Description

This command sets a port’s RSTP settings.

Examples

The following command sets Port 4’s port cost to 1 000 000 and it’s port
priority to 224:

set rstp port=4 portcost=1000000 portpriority=14

The following command changes Ports 7 to 10 so they are not
considered as edge ports:

set rstp port=7-10 edgeport=no

The following command returns Port 11 to the default RSTP settings:

set rstp port=1 default
