Allied Telesis AR400 Series Router User Manual
Page 37
Getting Started with the Graphical User Interface (GUI)
37
Software Release 2.6.1
C613-02021-00 REV D
Figure 8: An example of a configuration page with a selection table
Figure 9: An example of a popup “add” page
Heading row
Add, Modify and
Remove buttons
Radio button
Tabs
Select list
Apply and Cancel
buttons
Checkbox
Text field
