108 AR400 Series Router User Guide
Software Release 2.6.1
C613-02021-00 REV D
Configuring IPX
This example (Figure 16 on page 108) illustrates the steps required to configure
a pair of AR410 routers to create a Novell® IPX internetwork, using the
router’s command line interface. In this scenario, PCs at a remote office need
access to a Novell file server at the Head Office site. The two sites are connected
by a PPP link over a wide area link—either a dedicated leased line or an ISDN
call.
Figure 16: Example configuration for an IPX network.
Head Office Router
Network = 401
Remote Office Router
Network = 12
Netware
File Server Remote PC Remote PC
PPP Data Link
Network = 129
UGIPX1_R
Table 13: Example configuration parameters for an IPX network .
Configuration Parameter Head Office Router Remote Office Router
Ethernet interface eth0 eth0
Ethernet encapsulation 802.3 802.3
Novell network number for Ethernet 401 12
IPX circuit over Ethernet 1 1
PPP interface ppp0 ppp0
Novell network number for PPP 129 129
IPX circuit over PPP 2 2
