local (i.e. via eth0) on one router, should also be visible on the other router, via the PPP
link.
Test that a workstation on the Remote Office LAN can login to the file server
on the Head Office LAN.
4.
Save the Configuration
Save the new dynamic configuration as a script, by entering the command:
CREATE CONFIG=IPXCONF.SCP
To add an IPX circuit over a VLAN
1.
Define the IPX interface name
To create IPX circuit 1 with the Novell network number 129 over the admin
VLAN, enter the command:
ADD IPX CIRC=1 INTERFACE=vlan11 NETWORK=129 ENCAP=802.3
2.
Show the configuration
Show the new configuration by entering the command:
SHOW IPX CIRCUIT
The display should look like that shown in Figure 17. To interpret output from
the SHOW IPX CIRCUIT command see the Novell IPX chapter in the AR400
Series Router Software Reference.
Figure 17: Example output from the SHOW IPX CIRCUIT command.
IPX CIRCUIT information
Name ......................... Circuit 1
Status ....................... enabled
Interface .................... vlan11 (802.3)
Network number ............... c0e7230f
Station number ............... 0000cd000d26
Link state ................... up
Cost in Novell ticks ......... 1
Type20 packets allowed ....... no
On demand .................... no
Spoofing information
Keep alive spoofing .......... no
SPX watch dog spoofing ....... no
On SPX connection failure .... UPLINK
On end of SPX spoofing ....... UPLINK
RIP broadcast information
Change broadcasts ............ yes
General broadcasts ........... yes
General broadcast interval ... 60 seconds
Maximum age .................. 180 seconds
SAP broadcast information
Change broadcasts ............ yes
General broadcasts ........... yes
General broadcast interval ... 60 seconds
Maximum age .................. 180 seconds
Filter information
Filters ...................... none
