Description

4

Store and forward switching mode

Automatic address learning and aging

IEEE 802.3u compliant auto-negotiation

For use on a desktop or in an AT-MCR12 chassis

Status LEDs

Table 2 defines the LEDs for the switches.

External AC/DC Power Adapter

The power adapter supplies 12V DC to the switch. Allied Telesyn supplies an
approved safety compliant AC power adapter for the 100 and 240V AC
versions with an unregulated output of 12V DC.

Table 2 LEDs

LED

Color

Description

PWR

Green

Power is applied to the switch.

LNK/ACT

Green

Blinking

A valid link has been established on the port.

Data is being received or transmitted on the port.

100M

Green

OFF

The twisted pair port is operating at 100 Mbps.

The twisted pair port is operating at 10 Mbps.

FD/COL

Green

OFF

Blinking

The switch is operating in full-duplex mode.

The switch is operating in half-duplex mode.

A collision has been detected on the port.

AUTO NEG

Green

OFF

Auto-negotiation on the twisted pair port is enabled.

Auto-negotiation on the twisted pair port is disabled.
