AT-FS20x and AT-FS202SC/FSx Series Installation Guide

3

Table 1 lists the maximum operating distances for the switches.

Table 1 Maximum Operating Distances

Features

The AT-FS20x and AT-FS202SC/FSx Series Switches have the following
features:

LEDs for unit and port status

Auto MDI/MDI-X

External AC/DC power adapters (North America, Continental Europe,
or United Kingdom)

DIP switches for configuring the ports

Half- or full-duplex operation on both ports

RJ-45 twisted pair connector

SC or ST fiber optic connector

Data packet forwarding and filtering at full wire speed (10 Mbps to
100 Mbps, 100 Mbps to 100 Mbps, and 10 Mbps to 10 Mbps)

Model

100Base-FX

10/100Base-TX

Connector

Maximum
Operating
Distance

1

1. Maximum distance for 100 Mbps optical datalinks is dependent on the following factors: type of optical fiber,

duplex mode of both end-nodes, and maximum optical loss budget for each of the optical fiber at the operating
optical wavelength.

Connector

Maximum
Operating
Distance

2

2. Maximum distance can only be obtained when the UTP/STP cabling is installed and verified to TIA/EIA 568A

Commercial Building Telecommunications Cabling Standard.

AT-FS201

ST

2 km (1.2 mi)

RJ-45

100 m (328 ft)

AT-FS202

SC

2 km (1.2 mi)

RJ-45

100 m (328 ft)

AT-FS202SC/FS1

SC

15 km (9.3 mi)

RJ-45

100 m (328 ft)

AT-FS202SC/FS2

SC

40 km (24.8 mi)

RJ-45

100 m (328 ft)

AT-FS202SC/FS3

SC

75 km (46.5 mi)

RJ-45

100 m (328 ft)

AT-FS202SC/FS4

SC

100 km (62 mi)

RJ-45

100 m (328 ft)
