Allied Telesyn AT-VIEW PLUS
AMIGO
3.3 MIB Operation Panel
The MIB Operation Panel is the area at the bottom right corner of AMIGO's main window. It shows
the value of the variables selected in the MIB tree. To display the values of the MIB objects, first
select the object(s) on the MIB tree panel, then select an appropriate SNMP command from the
menu bar or toolbar.
In this panel, you can also change (set) the value of the variables.
Note - The threshold button cannot be used in AMIGO.
Topics:
• Checkbox Column
• MIB Variable Column
• MIB Value Column
• Select All Button
• Clear Button
• Reverse Button
• Get MIB Value Button
• Set MIB Value Button
MIB Operation Panel
This panel shows a table with the following columns.
3.3.1 Checkbox Column
The leftmost column shows whether or not the variable can be changed. If the column has a
checkbox in it, the variable can be changed.
