AT-S63 Management Software Command Line User’s Guide
Section II: Advanced Operations 325
SHOW QOS POLICY
Syntax
show qos policy[= idnumber ]
Parameter
policy Specifies the ID of the policy you want to view. You can
specify more than one policy at a time. Separate multiple
policies with commas (e.g., 4,5,10).
Description
This command displays the policies on a switch. An example is shown in
Figure 28.
Figure 28. SHOW QOS POLICY Command
This command provides the following information:
ˆ Policy ID - The policy’s ID number.
ˆ Description - The policy’s description.
ˆ Remark DSCP - Specifies whether the DSCP value of ingress packets
is overwritten. If All is specified, all packets are remarked. If None is
specified, the function is disabled. The default is None.
ˆ In DSCP overwrite - The replacement value to write into the DSCP
(TOS) field of the packets.
ˆ ToS - Specifies a replacement value to write into the Type of Service
(ToS) field of IPv4 packets. The range is 0 to 7. A ToS value specified
at the policy level is used only if no value has been specified at the flow
group and traffic class levels.
ˆ Move ToS to Priority - If set to yes, replaces the value in the 802.1p
priority field with the value in the ToS priority field on IPv4 packets. If
set to No, which is the default, the packets retain their preexisting
Policy ID ................ 11
Description .............. policy_ca2
Remark DSCP .............. All
In DSCP overwrite ........ 42
ToS ......................
Move ToS to Priority ..... No
Move Priority to ToS ..... No
Send to Mirror Port ...... No
Traffic Class List .......
Redirect Port ............
Ingress Port List ........ 15
Egress Port ..............
Is Active ................ Yes
