Installing Windows Server 2003 and Windows XP Driver Software
56
Rx TCP/IP Checksum - Enables receive TCP, IP, and UDP
checksum offloading.
Tx TCP/IP Checksum - Enables transmit TCP, IP, and UDP
checksum offloading.
Tx/Rx TCP/IP Checksum (default) - Enables transmit and receive
TCP, IP, and UDP checksum offloading.
7. Click OK.
8. If prompted to restart your computer, click Yes.
Although it is not necessary to reboot the system for new adapter
properties to take effect, rebooting is recommended to reinitialize all
registers.
9. Verify that the adapter port LEDs operate as described in “Physical
Flow Control
The Flow Control property allows you to enable or disable the receipt or
transmission of PAUSE frames which enable the adapter and the switch to
control the transmit rate. The port side that is receiving the PAUSE frame
momentarily stops transmitting. The recommended selection is Disable,
which configures the adapter to ignore PAUSE frames.
By default, the Flow Control property is set to disabled.
Note
You must have Administrator privileges to update the driver
software.
To change the Flow Control property, perform the following procedure:
1. Start either a Windows Server 2003 system or a Windows XP system
and log in.
2. On the desktop, right click My Computer and select “Properties.”
The System Properties dialog box opens, as shown in Figure 22 on
page 48.
3. In the “Hardware tab” on the System Properties dialog box, select
“Device Manager.”
The Device Manager window is shown in Figure 24 on page 50.
4. Click the “+” next to the Network Adapters folder. Then double click on
the desired Allied Telesis network adapter.
