AT-WNP300N IEEE802.11b/g/n 1T2R Wireless Fast PCI adapter User Manual 31
Chapter 5: Utility Introduction
Profile
This page shows saved profile information and operation.
Figure 49: Profile
Profile List
Add: Add a new profile. Press “Add” and configure “System
config” and “Auth.\Enery” tabs to finish the setting.
Edit: Edit a profile. Select the profile you want to edit and press
“Edit”.
Delete: Delete a profile. Select the profile you want to delete and
press “Delete”.
Active: Active a selected profile.
Profile Name Name of the AP in profile list
SSID SSID of the AP in profile list
Network Type Network type of the AP in profile list
Authentication Authentication of the AP in profile list
Encryption Encryption of the AP in profile list
Use 802.1x Whether the AP supports 802.1x
Tx Power Tx power of the AP in profile list
Channel Channel of the AP in profile list
Power Save Mode Power saving setting of the AP in profile list
RTS Threshold RTS Threshold setting of the AP in profile list
Fragment Threshold The fragment threshold of the AP in profile list
Status The SSID and Mac address of the connecting AP
Extra Info The connection status and the strength of the connecting AP
Channel The channel of the connecting AP
Authentication The authentication of the connecting AP
Encryption The encryption setting of the connecting AP
Network Type The network type of the connecting AP
IP Address Obtained IP of this computer
Submask
Current submask
Default Gateway
Current default gateway
More/Less
Switch to show more or less information
