AT-WNP300N IEEE802.11b/g/n 1T2R Wireless Fast PCI adapter User Manual 25
4. In “Profile” tab, select the profile from profile list, and then click on “Active”.
Figure 33: Active a Non-broadcasting Network
Note: The SSID and encryption settings must be exactly the same with the wireless AP,
otherwise it will result in a failure.
1. In “Network” tab, select the AP you want to connect to. Non-broadcasting SSID is blank in SSID
column, as shown in figure 34. Click on “Add to Profile”.
Figure 34: Select a Non-broadcasting SSID
2. In “System Config” tab, give the profile a name to identify, and then input SSID. The SSID must be
exactly the same with the wireless AP.
Figure 35: Configure Profile Name
3. In “Auth.\Encry” tab, configure corresponding setting, including Authentication, Encryption and the
Key. Click on “OK” to apply the settings.
Figure 36: Configure Auth./Encry.
