AT-2716POE Fast Ethernet Fiber & PoE Adapter Installation and User’s Guide
90
Using a Swab
Specially treated swabs, known as stick cleaners, are available for
cleaning inside connector adapters or hard-to-reach ferrule tips. These
swabs, often referred to as “lint free” or “alcohol free” swabs, are available
from many vendors, as shown in Figure 48. Stick cleaners are available in
both 2.5 mm and 1.25 mm sizes for use on SC and MU connectors
respectively.
Note
NEVER use a household cotton swab and/or alcohol to clean a
fiber optic connector. This may leave a residue on the ferrule tip.
Figure 48. Lint-Free and Alcohol-Free Swabs
Note
Do not use compressed air or aerosol air to clean a fiber optic
connector.
To clean a recessed ferrule using a swab, perform the following
procedure.
1. Insert the swab into the adapter as shown in Figure 47 and rub the
ferrule tip with the swab.
Figure 49. Cleaning a Recessed Ferrule
2. If desired, repeat step 1.
